Getting to Know Engine StandThe AGSE Engine Stand PW4000/JT9D represents a pinnacle of aviation maintenance equipment, specifically engineered for handling Pratt & Whitney’s PW4000 and JT9D series engines. This versatile low-profile shipping stand combines robust construction with practical functionality, making it an indispensable tool for engine maintenance operations. Manufactured with high-grade structural steel conforming to ASTM standards, the stand features a Skydrol-resistant enamel coating that ensures longevity and protection against harsh aviation fluids.

Features and Applications Engine StandThis engine stand excels in versatility and operational efficiency. Its bootstrap capability enables seamless engine removal and installation operations, particularly optimized for MD-11 aircraft. The stand’s mobility system features four heavy-duty shock-absorbing caster assemblies, each equipped with 5″ wide x 10″ diameter polyurethane tread wheels. These wheels, rated at 5,000 LBS capacity each, ensure stable movement and precise positioning during maintenance procedures. The stand’s design prioritizes safety and convenience, incorporating position locks and face brakes on all casters. For transportation, it can be towed at speeds up to 3 MPH (5 Km/h) from either end. A secured document container on the base provides convenient storage for essential maintenance documentation. The stand’s compatibility with major freight aircraft, including B747, DC-10, and MD-11, enhances its logistics versatility.

Technical Design and EngineeringThe engineering excellence of this stand is evident in its adaptable design and robust construction. External truck shipping shock mounts provide additional protection during transportation. The stand’s dimensions are optimized for both storage and operational efficiency, with adjustable height capabilities through extended casters. Its structural integrity is maintained even under maximum load conditions, demonstrating AGSE’s commitment to safety and reliability in aviation maintenance equipment.

Part Number: AGSE-E006
Compatible Engines: PW4000-94, JT9D series
Base Support: 4 shock-absorbing caster assemblies
Wheel Specifications: 5″ wide x 10″ diameter
Caster Capacity: 5,000 LBS each
Maximum Towing Speed: 3 MPH (5 Km/h)
Dimensions without Engine: – Height: 50.0″ (54.0″ extended) – Width: 100.0″ – Length: 196.0″ – Weight: 4,580 LBS
Dimensions with PW4000 Engine: – Height: 99.0″ (103.0″ extended) – Width: 100.0″ – Length: 196.0″ – Weight: 15,580 LBS
Construction: ASTM-standard structural steel
Finish: Skydrol-resistant enamel coating
Aircraft Compatibility: B747, DC-10 & MD-11 freighters
